BF135 (135HP OUTBOARD)
In Stock- POA
Product Details
Honda's BF135 delivers seamless performance and optimum power for a smooth and enjoyable boating experience. Based on the same reliable engine that powers the globally-popular Honda Accord, it has been manufactured with the world's most innovative, efficient and reliable technology.
The BF135 offers power-to-weight ratios to rival two-stroke engines in the same class. Designed for use in all environments, this engine features a unique set of Honda-exclusive technologies to provide increased power across the entire rev range.
Low fuel consumption, exceptional reliability and reduced periodical maintenance requirements all combine to minimise the overall cost of ownership.
ENGINE
TYPE4-stroke DOHC inline 4-cylinder / 16-valves
DISPLACEMENT2,354cc
BORE & STROKE87 x 99 mm
FULL THROTTLE RPM RANGE5,000-6,000 RPM
RATED POWER135HP @ 5,500 RPM
COOLING SYSTEMWater cooled
INDUCTIONProgrammed fuel injection
IGNITION SYSTEMFull transistorised battery ignition
STARTING SYSTEMElectric
EXHAUSTThrough prop
ALTERNATOR40-Amp
POWER TRIM & TILTStandard
TRIM RANGE-4° to +16°
TILT RANGE72°
SAFETY FEATURES
EMERGENCY STOP SWITCHStandard
OIL PRESSURE ALERTStandard
TEMPERATURE ALERTStandard
REV-LIMITERStandard
SPEEDOMETER PICKUPStandard
DRIVE
GEAR RATIO2.14:1
GEAR SHIFTF-N-R
PROPELLEROptional
DIMENSIONS
OVERALL LENGTH845mm
OVERALL WIDTH580mm
OVERALL HEIGHT (L-TYPE)1,665mm
OVERALL HEIGHT (X-TYPE)1,790mm
OVERALL HEIGHT (XXL-TYPE)n/a
TRANSOM HEIGHT (L-TYPE)508mm
TRANSOM HEIGHT (X-TYPE)635mm
TRANSOM HEIGHT (XXL-TYPE)n/a
DRY WEIGHTS (L-TYPE)217kg
DRY WEIGHTS (X-TYPE)220kg
