BF15 (15HP OUTBOARD)
In Stock- POA
Product Details
Honda's BF15 delivers unrivalled innovation to the portable range. Ideally suited to 3-4.5 metre aluminium and inflatable boats, it provides responsive, smooth and reliable power in a lightweight design.
Honda's Advanced Four-Stroke Technology results in efficient, clean and quiet operation, making your time on the water more enjoyable than ever before.
The world-renowned quality of a Honda outboard combines proven reliability and superior fuel efficiency, with no oil mixing, also resulting in a healthier experience for you and the environment.
ENGINE
TYPE4-stroke SOHC 2-cylinders / 4-valves
DISPLACEMENT350cc
BORE & STROKE59 x 64 mm
FULL THROTTLE RPM RANGE4,500-5,500 RPM
RATED POWER15HP @ 5,000 RPM
COOLING SYSTEMWater Cooled
INDUCTION1 carburettor
IGNITION SYSTEMPGM-IG
STARTING SYSTEMRecoil/Electric
EXHAUSTThrough prop
ALTERNATOR12-Amp (electric) / 6-Amp (manual)
POWER TRIM & TILTn/a
GAS-ASSISTED TILTAvailable
TRIM RANGE4-stage 8° - 12° - 16° - 20°
TILT RANGE72°
SAFETY FEATURES
EMERGENCY STOP SWITCHStandard
OIL PRESSURE ALERTStanadrd
TEMPERATURE ALERTStandard
REV-LIMITERStandard
SPEEDOMETER PICKUPn/a
DRIVE
GEAR RATIO2.08:1
GEAR SHIFTF-N-R
PROPELLER4-blade aluminium
DIAMETER X PITCH (S-TYPE)9-1/4 x 10 inches
DIAMETER X PITCH (L-TYPE)9-1/4 x 10 inches
DIAMETER X PITCH (X-TYPE)n/a
DIMENSIONS
OVERALL LENGTH650mm
OVERALL WIDTH350mm
OVERALL HEIGHT (S-TYPE)1,110mm
OVERALL HEIGHT (L-TYPE)1,240mm
OVERALL HEIGHT (X-TYPE)n/a
TRANSOM HEIGHT (S-TYPE)433mm
TRANSOM HEIGHT (L-TYPE)563mm
TRANSOM HEIGHT (X-TYPE)n/a
DRY WEIGHTS (S-TYPE)46.5kg
DRY WEIGHTS (L-TYPE)46.5kg
DRY WEIGHTS (X-TYPE)n/a
