BF175 (175HP OUTBOARD)
In Stock- POA
Product Details
By sharing many components with the Honda Odyssey and Honda Pilot, the BF175 gains years of proven Honda engineering, precision manufacturing and reliability.
The BF175 features a Large Displacement Engine with a powerful, compact 24-valve SOHC design. Lacking the bulk and weight of long intake runners and multi-camshafts, the narrow V6 design offers top performance and durability, based on Honda's automotive engineering excellence.
The High Performance Gearcase is designed to get you going faster, all the while reducing hull porpoising and minimising spray, thus increasing acceleration and top speed.
ENGINE
TYPE4-stroke SOHC 60 ° V6 / 24-valves
DISPLACEMENT3,471cc
BORE & STROKE89 x 93 mm
FULL THROTTLE RPM RANGE5000-6000 RPM
RATED POWER175HP @ 5,500 RPM
COOLING SYSTEMWater cooled (Thermostatically controlled)
INDUCTIONProgrammed fuel injection
IGNITION SYSTEMMicro-computer programmed
STARTING SYSTEMElectric
EXHAUSTThrough Prop
ALTERNATOR60-Amp
POWER TRIM & TILT72 °
TRIM RANGE-4 ° to +16 °
TILT RANGE72 °
SAFETY FEATURES
EMERGENCY STOP SWITCHStandard
OIL PRESSURE ALERTStandard
TEMPERATURE ALERTStandard
REV-LIMITERStandard
SPEEDOMETER PICKUPStandard
DRIVE
GEAR RATIO1.87:1
GEAR SHIFTF-N-R
PROPELLEROptional
DIMENSIONS
OVERALL LENGTH920mm
OVERALL WIDTH625mm
OVERALL HEIGHT (L-TYPE)n/a
OVERALL HEIGHT (X-TYPE)1,800mm
OVERALL HEIGHT (XXL-TYPE)n/a
TRANSOM HEIGHT (L-TYPE)n/a
TRANSOM HEIGHT (X-TYPE)635
TRANSOM HEIGHT (XXL-TYPE)n/a
DRY WEIGHTS (L-TYPE)n/a
DRY WEIGHTS (X-TYPE)272
