BF2.3 (2.3HP OUTBOARD)
In Stock- POA
Product Details
Not only does the BF2.3 pack enough punch to push a boat out to sea, it's light enough to be carried back to the car! Thanks to the ergonomic carry handle fitted to each engine, the BF2.3 can be taken virtually anywhere.
Despite the engine's size, the BF2.3 boasts all the benefits of Honda's advanced four-stroke technology, which is second to none.
The BF2.3 is the lightest 2.3hp four-stroke available - even lighter than most two-stroke outboards!
ENGINE
TYPE4-stroke OHV 1-cylinder / 2-valves
DISPLACEMENT57cc
BORE & STROKE45 x 36 mm
FULL THROTTLE RPM RANGE5,000-6,000 RPM
RATED POWER2.3HP @ 5,500 RPM
COOLING SYSTEMForced air
INDUCTION1 carburettor
IGNITION SYSTEMTransistorised Pointless
STARTING SYSTEMRecoil
EXHAUSTUnder water, above propeller
ALTERNATORn/a
POWER TRIM & TILTn/a
GAS-ASSISTED TILTn/a
TRIM RANGE4-stage 5 ° - 10 ° - 15 ° - 20 °
TILT RANGE75°
SAFETY FEATURES
EMERGENCY STOP SWITCHStandard
OIL PRESSURE ALERTn/a
TEMPERATURE ALERTn/a
REV-LIMITERn/a
SPEEDOMETER PICKUPn/a
DRIVE
GEAR RATIO2.42:1
GEAR SHIFT360° pivot
PROPELLER3-blade plastic
DIAMETER X PITCH (S-TYPE)7-1/4 x 4-3/4 inches
DIAMETER X PITCH (L-TYPE)7-1/4 x 4-3/4 inches
DIAMETER X PITCH (X-TYPE)n/a
DIMENSIONS
OVERALL LENGTH410mm
OVERALL WIDTH280mm
OVERALL HEIGHT (S-TYPE)945mm
OVERALL HEIGHT (L-TYPE)1,100mm
OVERALL HEIGHT (X-TYPE)n/a
TRANSOM HEIGHT (S-TYPE)418mm
TRANSOM HEIGHT (L-TYPE)571mm
TRANSOM HEIGHT (X-TYPE)n/a
DRY WEIGHTS (S-TYPE)12.2kg
DRY WEIGHTS (L-TYPE)12.7kg
DRY WEIGHTS (X-TYPE)n/a
