BF200 (200hp Outboard)
In Stock- POA
Product Details
DESIGN
Debuting the new Honda Progressive V Form, with aerodynamic lines and an emphasized “V” with the centre grille and chrome line detail, exhibiting an elegant, aerodynamic design aesthetic. The new design also delivers boaters increased engine cover durability, better protection from water entering the engine and protection from paint chips and scrapes.
The outboard is equipped with a three-latch lock and seal system and two inverted grip points that make the cover easy to remove and carry—the first step in easy maintenance. To enhance performance and provide better protection from water intrusion, the new cowling incorporates a dual channel, indirect-air-circuit induction system improving airflow while helping funnel moisture away from the throttle body.
The undercase design has been streamlined to incorporate three pieces (instead of seven on the previous model), along with a heavy protective rubber edge at the base of the cowling, further protecting against outside elements and increasing durability.
TECHNOLOGY
The technology applied to the refreshed Honda BF200 V6 engine is derived from the very same technology that powers Honda automobiles such as the Honda Ridgeline, Honda Odyssey, and Honda Pilot, gaining from years of proven Honda engineering, precision manufacturing and reliability. This cross-platform integration of technology illustrates the Honda commitment to high performance, fuel efficiency and environmental excellence for its customers. Key technologies include:
● Programmed Fuel Injection (PGM-FI) delivers precise amounts of fuel and air to each cylinder, resulting in quick starts, instant throttle response and low fuel consumption. PGM-FI employs microprocessor technology to accurately control the ignition timing during start-up and across the entire rpm range, providing optimum overall operation.
● Boosted Low Speed Torque (BLAST™) System dramatically improves performance and acceleration by advancing ignition timing during ‘hammer down’ acceleration. The Engine Control Module (ECM) steps in to increase injector timing, creating a more potent air/fuel mixture. The resulting boost in available torque at low rpm contributes to a strong holeshot to get the boat up on plane quickly.
● Lean Burn Control automatically adjusts the air/fuel mixture according to speed and load while maximizing power throughout the acceleration range, increasing fuel efficiency in cruise mode (2,000 to 4,500 rpm).
MAINTENANCE
The revamped Honda V6 engine also features a number of enhancements for improved reliability and ease of maintenance. Corrosion resistance is improved with a new coating on the surface of engine hardware that utilizes a chemically treated, zinc-nickel plating with a high corrosion-resistant top coat. In addition, components including the oil pan, thermostat cover, upper mount cover, and prop shaft holder use a higher corrosion-resistant material, resulting in a more durable engine and gear case. Finally, the number of anodes on each engine’s V bank has been increased from two to four And for more time on the water, routine maintenance time is reduced for activities such as oil and filter changes on the refreshed V6 outboard, courtesy of a larger diameter dipstick tube, the integration of a water separator and fuel strainer and relocation of the high-pressure filter (from the high-pressure pump) for easier access. For example, changing a high-pressure fuel filter on any of the new V6 motors now can take as little as five minutes as compared to the 60 minutes on existing models.
ENGINE
TYPE
4-Stroke, SOHC, 60˚ V6, 24 Valve
DISPLACEMENT
3583cc
BORE & STROKE
89 mm x 96 mm
FULL THROTTLE RPM RANGE
5000 - 6000 RPM
RATED POWER
200 HP (147.1kW) @ 5500 RPM
COOLING SYSTEM
Water Cooled
FUEL DELIVERY
Programmed Fuel Injection
IGNITION SYSTEM
Micro-Computer Programmed
STARTING SYSTEM
Electric
EXHAUST
Through Hub
LUBRICATION
Wet Sump
TRIM RANGE
-4° to +16°
TILT RANGE
68°
DRIVE
GEAR RATIO 2.00:1 (24/12)
GEAR SHIFT
F-N-R
ALTERNATOR
12V 60Amp
BATTERY CHARGING POWER
60Amp
PROPELLER
Optional
POWER TRIM & TILT Standard
OIL PRESSURE ALERT
Standard
TEMPERATURE ALERT
Standard
REV-LIMITER Standard
SPEEDOMETER PICKUP
Standard
DIMENSIONS
OVERALL WIDTH
660mm
OVERALL LENGTH
948mm
OVERALL HEIGHT - L TYPE
1789mm
OVERALL HEIGHT - XL TYPE 1916mm
OVERALL HEIGHT - UL TYPE 2043mm
TRANSOM HEIGHT
L TYPE
N/A
XL TYPE
635mm
UL TYPE
N/A
DRY WEIGHT
L TYPE N/A
XL TYPE
285kg
UL TYPE N/A
