BF50 (50HP OUTBOARD)
In Stock- POA
Product Details
The new ‘crouching’ style of the BF50 unifies the design of all small and medium sized outboards across the range.
The ‘crouching’ form gives the outboards a strong and athletic appearance to match the technology packed engine contained within the simple and sleek silver cowl.
With an upgraded ECU the new BF50 engines have the latest in Electronic Fuel Injection (EFI) technology. This ensures that fuel is delivered to the engine in a highly efficient and precisely measured manner.
ENGINE
TYPE4-stroke SOHC 3-cylinders / 6-valves
DISPLACEMENT808cc
BORE & STROKE70 x 70 mm
FULL THROTTLE RPM RANGE5,500-6,000 RPM
RATED POWER50HP @ 5,750 RPM
COOLING SYSTEMWater cooled
INDUCTIONProgrammed Fuel Injection (PGM-FI)
IGNITION SYSTEMTransistorised battery ignition
STARTING SYSTEMElectric
EXHAUSTThrough prop
ALTERNATOR17-Amp
POWER TRIM & TILTAvailable
GAS-ASSISTED TILTAvailable
TRIM RANGE-4° to +16°
TILT RANGE63°
SAFETY FEATURES
EMERGENCY STOP SWITCHStandard
OIL PRESSURE ALERTStandard
TEMPERATURE ALERTStandard
REV-LIMITERStandard
SPEEDOMETER PICKUPStandard
DRIVE
GEAR RATIO2.08:1
GEAR SHIFTF-N-R
PROPELLER3-Blade Aluminium
DIAMETER X PITCH (S-TYPE)n/a
DIAMETER X PITCH (L-TYPE)11-1/4 x 13 Inches
DIAMETER X PITCH (X-TYPE)11-3/4 x 10 Inches
DIMENSIONS
OVERALL LENGTH694mm
OVERALL WIDTH390mm
OVERALL HEIGHT (S-TYPE)1,281mm
OVERALL HEIGHT (L-TYPE)1,387mm
OVERALL HEIGHT (X-TYPE)1,465mm
TRANSOM HEIGHT (S-TYPE)n/a
TRANSOM HEIGHT (L-TYPE)521mm
TRANSOM HEIGHT (X-TYPE)622mm
DRY WEIGHT100kg
