BF75 (75HP OUTBOARD)
In Stock- POA
Product Details
The NEW BF75 is packed with power! Its 1.5L, SOHC, 16-valve, inline four-cylinder engine is inspired by the same remarkable engine that powers one of Honda's most popular motor vehicles, the Honda Jazz.
With the exception of the cylinder sleeves, this engine features an all-aluminium alloy block, resulting in a very lightweight and powerful package.
A range of Honda-exclusive technologies such as BLAST, ECOmo as well as an updated Electronic Fuel Injection (EFI) System topped off with the ‘Best in Class’ Charging Performance, it is no surprise that the all new BF75 is truly packed with power!
ENGINE
TYPEFour-Stroke SOHC 4 Cylinders
DISPLACEMENT1,496cc
BORE & STROKE73 x 89 mm
FULL THROTTLE RPM RANGE5000-6000 RPM
RATED POWER75HP @ 5,500 RPM
COOLING SYSTEMWater Cooled
INDUCTIONProgrammed Fuel Injection
IGNITION SYSTEMFully Transistorised Barry Ignition
STARTING SYSTEMElectric
EXHAUSTThrough prop
ALTERNATOR44-Amp
POWER TRIM & TILTStandard
TRIM RANGE-4° to +16°
TILT RANGE68°
SAFETY FEATURES
EMERGENCY STOP SWITCHStandard
OIL PRESSURE ALERTStandard
TEMPERATURE ALERTStandard
REV-LIMITERStandard
SPEEDOMETER PICKUPStandard
DRIVE
GEAR RATIO2.33:1
GEAR SHIFTF-N-R
PROPELLEROptional
DIMENSIONS
OVERALL LENGTH746mm
OVERALL WIDTH449mm
OVERALL HEIGHT (L-TYPE)1,566mm
OVERALL HEIGHT (X-TYPE)1,693mm
OVERALL HEIGHT (XXL-TYPE)n/a
TRANSOM HEIGHT (L-TYPE)537mm
TRANSOM HEIGHT (X-TYPE)664mm
TRANSOM HEIGHT (XXL-TYPE)n/a
DRY WEIGHT165kg
