BF90 (90HP OUTBOARD)
In Stock- POA
Product Details
The technology in the BF90 is the very same that powers one of the most popular cars in the world, the Honda Jazz!
The BF90 offers PGM-FI for instant throttle response and optimized fuel consumption. It also features Honda exclusives like BLAST™ for strong acceleration, Lean Burn Control for superior fuel efficiency and a 3-Way Cooling System for long-lasting, durable performance.
Add it all together and you have an engine that is economical, efficient and durable — which means maximum quality time for you on the water.
ENGINE
TYPEFour-stroke SOHC 4 Cylinders
DISPLACEMENT1,496cc
BORE & STROKE73 x 89 mm
FULL THROTTLE RPM RANGE5,300-6,300 RPM
RATED POWER90HP @ 5,800 RPM
COOLING SYSTEMWater Cooled
INDUCTIONProgrammed Fuel Injection
IGNITION SYSTEMFull Transistorised Battery Ignition
STARTING SYSTEMElectric
EXHAUSTThrough prop
ALTERNATOR44 amp
POWER TRIM & TILTStandard
TRIM RANGE-4° to +16°
TILT RANGE68°
SAFETY FEATURES
EMERGENCY STOP SWITCHStanard
OIL PRESSURE ALERTStandard
TEMPERATURE ALERTStandard
REV-LIMITERStandard
SPEEDOMETER PICKUPStandard
DRIVE
GEAR RATIO2.33:1
GEAR SHIFTF-N-R
PROPELLEROptional
DIMENSIONS
OVERALL LENGTH746mm
OVERALL WIDTH449mm
OVERALL HEIGHT (L-TYPE)1,566mm
OVERALL HEIGHT (X-TYPE)1,693mm
OVERALL HEIGHT (XXL-TYPE)n/a
TRANSOM HEIGHT (L-TYPE)537mm
TRANSOM HEIGHT (X-TYPE)664mm
TRANSOM HEIGHT (XXL-TYPE)n/a
DRY WEIGHT166kg
